The B.dac one incorporates our patented SJR “Source Jitter Removal” technology. It provides optimal conversion quality, even from sources subject to a significant level of jitter, regardless of the input (USB, AES-EBU, SPDIF or TOSLINK optical).

Design

Adopting the refined aesthetics typical of B.audio products, the B.dac one features a visually screwless enclosure, which includes a massive CNC machined aluminum front panel fitted with an OLED display housed in a glass window.

Power supplies

Like our reference models, the B.dac one has a dual power supply that separates the digital domain from the analog domain. The transformers are sized accordingly to ensure perfect operating stability.

Oversampling

The B.dac one uses a linear phase digital filtering system that has been optimized to prevent pre-echo phenomenon and guarantees an optimal transient response. This oversampling process is embedded in a DSP that employs in-house developed algorithms.

Output stage

The B.dac one features a 100% balanced analog output stage with low-phase deviation filters like our reference converters.

₹1,495,200.00

Description

GENERAL
Power supply	Factory set : 220-230V or 100-115V, 50-60Hz
Dimensions	450x375x91mm
Weight	6,9kg

TECHNICAL
Power stage total capacity	> 45 000µF
Power stage regulation	multiple, linear
Conversion type	multibit sigma-delta
Clock management	patented SJR technology

DIGITAL IN
Connectors	2x SPDIF, 2x Toslink, 1x AES/EBU, 1x USB (type B)

USB (type B)
operating mode	asynchronous
Supported format	PCM (incl. DXD), DSD, DSD over PCM (DoP)
Sample rate (PCM)	44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz (DXD), 384kHz
Word length (PCM)	16, 24, 32 bits
Data rate (DSD)	2.8224MHz (DSD64), 5.7648MHz (DSD128), 11.2896MHz (DSD256)
Data rate (DSD over PCM)	2.8224MHz (DSD64), 5.7648MHz (DSD128)

SPDIF and AES/EBU
Supported format	PCM
Sample rate (PCM)	44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
Word length (PCM)	16, 24 bits

Toslink
Supported format	PCM
Sample rate (PCM)	44.1kHz, 48kHz, 88.2kHz, 96kHz
Word length (PCM)	16, 24 bits

ANALOG OUT
Balanced
Connectors	XLR
Output impedance:	100 Ohms

Unbalanced
Connectors	RCA
Output impedance:	75 Ohms
